Motors

ABB Motors

ABB general performance induction motors are engineered to the highest standards to deliver superior reliability and efficiency. Ideal for industries such as water and wastewater, HVAC, agriculture and general machinery, these high-quality motors are also perfect for OEMs integrating them into various applications such as compressors, pumps, fans. Our cast iron motors offer exceptional durability, efficiency, and performance for demanding industrial environments. Built with a cast iron frame, these high-performance motors resist mechanical stress, corrosion, and harsh conditions. Available in IE2, IE3, and IE4 efficiency classes, they optimize energy consumption while reducing vibrations and noise for greater reliability.

Why choose ABB’s IEC Low voltage motors?

Available in efficiency classes IE2 to IE4
Series 62 or 63 bearings
Smaller sizes have bearings that are lubricated for life
A class C3 paint system protects against tough conditions
Some standard designs are available from stock, while customer and application specific solutions are manufactured to order and can be tailored to meet specific needs

Sector specific motors

As the world market leader, ABB offers the largest range of LV motors available. It has long advocated the need for efficiency in motors, and high efficiency products have formed the core of its portfolio for many years. The core of ABB’s Process performance range is based on a full range of IE2 and IE3 motors – with many available from stock. We also supply IE4 motors for additional energy savings.

General performance IE3 motors are ideal for OEMs to build into pumps and fans, as well as for other applications including gear boxes, conveyors and general machinery. The robust, straightforward motors meet all basic requirements on the market.

In order to meet the competitiveness, ABB has developed a motor with a classic streamlined appearance, that is compact in size. The use of materials, both electrically and mechanically, has been optimised and enhanced to meet today’s needs.

Flexible product, fit for purpose

Global customer support

Online product documentation

Target segments HVAC, food and beverage, water and waste water, power

IE3 Motors: Product offering

Motor type: General performance M2BAX 71-355
Rated output: 0,25 to 355 kW
Poles 2 to 6 poles
Voltage, frequency: 230-400 V, 50/60 Hz
Mounting: B3, B5, B14, B35, B34
Ambient temperature: -20°C to +40°C
Cooling IC411, TEFC
Efficiency IE3
Protection IP55 as standard
Insulation F / B
Stator protection: Thermistor +150°C as standard
Certification: MEPS Standard CE
